Easy Installation !! It can be stick on the roof or the deck of marine.
16V 72W
Specification (Standard Test Conditions)
( 1000 W/m2, AM 1.5, 25 °C Cell Temperature) ：
•Dimension ： 2849 x 394 x 4 mm
•Certificate ： UL / TUV
•Pma ： 72W
•Vm ：17.6 V
•Im ：4.1 A
•Isc ：5.1 A
•Voc ：23.1 V
•Max fuse in series ：8A
•Production Pmax Tolerance: ± 5 %
Application Criteria
• Installation temperature between 10 °C - 40 °C (50 °F - 100 °F)
• Maximum roof temperature: 85 °C (185 °F)
• Minimum slope: 3° (1/2:12)
• Maximum slope: 60° (21:12)
• Approved substrates include certain membrane and metal roofing products.
|
